• 'Measurements with the DG8SAQ VNWA 2/3 Vector Network Analyzer' (A4 Colour Softback Book)

Get Results Fast from your DG8SAQ VNWA 2/3 with

Gerfried Palme's Step-by-Step Guide for Beginners

This 165 page book features 28 guided measurement examples

using easy to follow text and graphics including:

  • Basic Settings
  • Calibration Standards & Settings
  • Reference Planes & Phase
  • Smith Charts
  • S-Parameter Test Set
  • Amplifier Measurements
  • Antenna Matching
  • Phase Angle
  • Wave Resistance

Table of Contents in Full
Read Sample Pages

English Translation by Graham McLead G8PHA (SK 26 June 2015)

Original German Language Version, 'Messen Mit dem Vektor-Netzverk Analysator VNWA 2/3' available from Funkamateur

Also available:  VNWA Test board Kit designed by DG8SAQ - As featured in Chapter 24!  Experiment & evaluate performance with simple circuits

'Measurements with the DG8SAQ VNWA 2/3 Vector Network Analyzer' (A4 Colour Softback Book)

  • Product Code: A4 VNWA English Language Colour Softback Book
  • Availability: In Stock
  • £28.75

  • incl VAT: £28.75
  • Indicative prices in EURO €33,64
  • Indicative prices in USD $36.67
